| Brand Name: | Beiaole |
| Model Number: | FM-125-20 |
| MOQ: | 1 unit |
| Price: | 20USD~70 USD |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 60000 pcs/month |
| Type | Air handling Unit | Mounting Type |
Ceiling Mount
|
| Fan Motor Type |
AC
|
Motor Type | Cross Flow Turbine |
|
Key Selling Points
|
Easy to operate,High Safety,Long Service Life
|
Warranty | 1 Year for the whole set 5 years for motor |
| Machinery Test Reports | Provided |
Video outgoing Insepction
|
Provided
|
|
Core Components
|
Motor | Place of Origin | Guangdong China |
|
Weight(kg)
|
7.5 | Brand name | Beiaole |
|
Model No.
|
FM-125-10 | Dimension(L*W*H) | 1000*145*185mm |
|
Name
|
Titan Series | Materials | Galvanized Sheet Sheell Metal Casing |
|
Air Speed
|
9-11 | Mounting Type | Ceiling Mounted |
|
Installation Height
|
2.5-3 meters | Package | Shipping Carton |
Choosing the right air curtain doesn't have to be complicated. The Hercules Series offers nine models to fit door widths from 600mm to 2000mm. Here's a quick guide to help you decide.
For narrow doors (600mm–1000mm):
FM-125-06 (600mm): 90W, 1200 m³/h, 50 dB, 5.5 kg
FM-125-09 (900mm): 90W, 1300 m³/h, 57 dB, 7 kg
FM-125-10 (1000mm): 115W, 1500 m³/h, 58 dB, 7.5 kg
For standard doors (1200mm–1500mm):
FM-125-12 (1200mm): 135W, 1700 m³/h, 58 dB, 8.5 kg
FM-125-15 (1500mm): 160W, 2150 m³/h, 59 dB, 10 kg
For wide doors (1800mm–2000mm):
FM-125-18 (1800mm): 185W, 2600 m³/h, 60 dB, 13 kg
FM-125-20 (2000mm): 200W, 2900 m³/h, 61 dB, 13.5 kg
High-performance models (extra airflow, lower noise):
FM-125-18s (1800mm): 200W, 3480 m³/h, 53 dB, 14 kg
FM-125-20s (2000mm): 240W, 3980 m³/h, 53 dB, 15 kg
All models share the same 145x185mm body profile and operate at 220V/50Hz with 9–11 m/s wind speed. Installation height: 2.5m–3m.
Need help choosing? Contact our team for personalized recommendations.
